NIBCO F-619 6" Gate Valve – Flanged 125 lb – Cast Iron – Handwheel – 200 PSI

NIBCO F-619 6" Gate Valve – Flanged 125 lb – Cast Iron – Handwheel – 200 PSI

Retail: $2,468

Description:
The NIBCO F-619 Gate Valve (Model NHAC00K) is a high-performance, flanged-end valve designed for industrial applications involving air, gas, or water. Built with a durable cast iron body and brass trim, this valve is rated for 200 PSI cold working pressure and up to 125 PSI saturated steam at 353°F.

This 6-inch valve features a handwheel actuator, non-rising stem, and a bolted bonnet, ensuring reliable performance in demanding environments.

Key Features:

• Brand: NIBCO

• Model: NHAC00K / Series F-619

• Size: 6 inch nominal

• End Style: Flanged

• Pressure Class: 125 lb

• Pressure Rating: 200 PSI cold / 125 PSI steam

• Temperature Rating: Up to 450°F

• Body Material: Cast Iron

• Trim Material: Brass / Bronze wedge

• Softgoods: Graphite

• Actuator Type: 12" Handwheel

• Inlet to Outlet Length: 10.5"

• Top to Inlet Center Height: 21"

• Media: Air, Gas, Water

• Stem: Non-rising

• Bonnet: Bolted

• Domestic Product

• NOTE: Not for use in U.S. drinking water systems post-Jan 3, 2014

Shipping:

$200 Freight or local pickup available in Columbus, KS.
